Limelight® Hot Tubs Collection


Relax and connect with the people who matter most to you.

The roomy interior seats up to seven adults in a spa that fits comfortably on most patios. It includes a jetted foot pod with seven precision directional jets for a penetrating foot massage from every seat.

What our customers are saying about the PULSE Hot Tub

Average rating: 3.8

Customise your Hot Tub

Choose your perfect cabinet and shell by clicking on the options below.

LoadingTop LoadingBtm
Relax and connect with the people who matter most to you.

PULSE Hot Tub Specs

Download Hot Tub Specs Sheet
Seating7 adults
Total jets49
Dimensions226 x 226 x 97 cm H
Water capacity1,685 liters
Dry weight460 kg dry
Filled weight2,700 kg filled
Lighting systemRaio™ multi-color interior points of light (32)
Exterior multi-color lighting with timer
Entertainment systems (optional)Wireless Entertainment
Control systemIQ 2020™ with LCD control panel 230v/20amp, 50Hz
Includes G.F.C.I. protected sub-panel
Jets1 XL Dual Rotary jet
1 XL Single Rotary jet
2 XL Directional jets
4 Standard Single Rotary jets
2 Standard Directional jets
4 Rotary Precision jets
35 Directional Precision jets
Jet pump 1Wavemaster™ 9200 Two-Speed 2.5 HP,
continuous duty 5.2 HP, breakdown torque
Jet pump 2Wavemaster™ 9000 One-Speed 2.5 HP,
continuous duty 5.2 HP, breakdown torque
Water featureVidro™ backlit ribbon waterfall
Circulation pumpSilentFlo 5000™ for quiet, continuous filtration
Ozone systemFreshWater® III Corona Discharge
Water care optionsACE® Salt Water System (Optional) or EverFresh® System
Effective filtration area9 m2, top-loading filters
Shell & cabinetAlpine White, Ice Gray, Platinum, Tuscan Sun or Desert
Coastal Gray, Espresso or Sable
Cover coloursCaramel
Cover options9 to 6 cm tapered, 32 kg/m3 density foam core, with hinge seal
Cover lifters (optional)CoverCradle™
CoverCradle II
Lift ‘n Glide™
Energy efficiencyFiberCor® insulation; Certified to the APSP 14
National Standard and the California Energy
Commission (CEC) in accordance with California law
HeaterNo-Fault™, 1,500w/230v
Show More


This advanced water care option is exclusively available from Hot Spring. The ACE Salt Water System uses a diamond electrode to create a powerful oxidiser and chlorine sanitiser that keep your spa water sparkling clean. With the ACE system, you'll add fewer bottled products to the water and enjoy better water quality with less maintenance.

360° View

Drag the hot tub left or right to see a detailed, 360-degree view of the spa seating, jet placement, spa shell and cabinet. Turn the spa to see the hot tub depth and look closely at the available jets.
